DA14533 Getting Started with the Pro-Development Kits

R19US0026EE0100

DA14533 Arm® Cortex® M0+ is a member of the DA1453x family of Bluetooth® Low Energy (BLE) devices, which operates at Ultra-low power levels while delivering top-notch RF performance. This tutorial will guide you to gain an understanding about the hardware and walk you through building and running your first DA14533 application by Keil®.

The DA14533 is optimized for automotive and industrial applications at higher temperatures, and it is rated as operating up to 105 ºC and compliant with the AEC-Q100 (Grade 2) standard.

Note

DA1453x here is referring to:

• DA14531-00

• DA14531-01

• DA14530

• DA14535

• DA14533.

Contents

• 1. Abstract
• 2. Prerequisites
• 3. Introduction
  • 3.1. Guide Purpose
  • 3.2. How long does it take to finish the tutorial?
  • 3.3. Unboxing the Package Content
• 4. The Hardware
  • 4.1. The DEVKT-P Motherboard
  • 4.2. What is new on DA1453x DEVKT-P Motherboard:
  • 4.3. The Daughterboard
  • 4.4. Configure the DEVKIT-P Motherboard with Jumper Settings
  • 4.5. Connecting the DEVKIT-P to the Host PC
• 5. Software Installation
  • 5.1. Requirements of the Development PC
  • 5.2. Driver Installation
  • 5.3. Serial Port for UART Configuration
• 6. Software Development Tools
  • 6.1. e² Studio and SDK6
  • 6.2. Keil Installation
• 7. Your First Application
  • 7.1. The Blinky Peripheral Example Application
  • 7.2. The Barebone BLE Example Application
  • 7.3. Troubleshooting
  • 7.4. What is the Next ?
• 8. Appendices
  • 8.1. SmartSnippets™ Studio
• 9. Terms and Definitions
• 10. Revision history
